Description
Parameters:
| Model | Hercules 6.8 | Hercules 8.3 | Hercules 10 |
|---|---|---|---|
| Pixel Pitch (mm) | 6.8 | 8.3 | 10 |
| Module Size W×H×D (mm) | 300 × 300 | 300 × 300 | 300 × 300 |
| Module Resolution W×H | 44 × 44 | 36 × 36 | 30 × 30 |
| Panel Size (mm) | 1200 × 1200 × 92 / 1200 × 900 × 92 | ||
| Panel Resolution | 176 × 176 / 176 × 132 | 144 × 144 / 144 × 108 | 120 × 120 / 120 × 90 |
| Weight (kg/㎡) | 27 | 27 | 27 |
| Brightness (nits) | 7000 | 10000 | 10000 |
| Panel Material | Aluminum | Aluminum | Aluminum |
| Serviceability | Front and Rear | Front and Rear | Front and Rear |
