Home / Outdoor LED screen / HerculesII-Outdoor Fixed LED Display
Description
Specifications:
| Model | Hercules II 6.67 | Hercules II 8 | Hercules II 10 |
|---|---|---|---|
| Pixel Pitch (mm) | 6.67 | 8 | 10 |
| Module Size W×H (mm) | 480 × 320 | 480 × 320 | 480 × 320 |
| Module Resolution W×H | 72 × 48 | 60 × 40 | 48 × 32 |
| Panel Size W×H×D (mm) | 960 × 1280 × 78 / 960 × 960 × 78 | ||
| Panel Resolution | 144 × 192 / 144 × 144 | 120 × 160 / 120 × 120 | 96 × 128 / 96 × 96 |
| Weight (kg/㎡) | 28 | 28 | 28 |
| Brightness (nits) | 7000 | 10000 | 10000 |
| Panel Material | Aluminum | Aluminum | Aluminum |
| Serviceability | Front / Rear | Front / Rear | Front / Rear |
